7 inches Quad LCD monitor reversing system

7 inches Quad LCD monitor reversing system Quad LCD monitor / Split LCD monitor rear view system LM-070Q-4C Features: MONITOR: --Built-in quad control box function --Support four camera inputs --With remote controller --Single View/Split view/Quad view selectable --7 languages OSD display --PAL/NTSC optional, MIRROR/NORMAL image optional --Automatically turn on when the reversing gear is engaged --Trigger priority: CAM 1>CAM 2>CAM 3>CAM 4 --With high-low voltage protection and short circuit protection Specification: (1)7 inch TFT LCD monitor ,16:9 (2)Wide view angle(CR>10): (up/down/left/right): 40/40/60/60 Degrees (3)Resolution:400 R.G.B x234 dots (4)Color system: PAL/NTSC(selectable) (5)Power requirement: 12/24V DC (6)Power consumption: less than 5W (7)Operating temperature: -20 to +70 C-degree (8)Storage temperature: -30 to +80 C-degree (9)Dimension: 183 (L) x 125 (W) x 38 (D) CAMERA: --4Pin DIN waterproof screw on connector --Standard rear view camera --The automatic day/night sensor and infrared LEDs to provide clear image in dull condition SPECIFICATIONS: (1)1/4" Sharp Color CCD sensor (2)TV system : PAL/NTSC (3)Resolution: 420 TV lines (4)With 18 IR LED light ,night vision distance up to 10-15 meters (5)Self-sensitization control the night vision function by the light sensor (6)120 degree wide range angle view (7)Operating Voltage: 9 12VDC (8)Operating temperature: -20 +70 degrees , RH95% Max. (9)Storage temperature: -40 +80 degrees , RH95% Max. (10)Alloy shell, Waterproof, silver/black color selectable CABLE: --4 Pole Screw Locking Extension Cable --Design for Car Rear View Systems using in long vehicle --One Male connect(4 pin) and the other female connector(4 socket) --Color: Black --Length: 5m, 15m, 20m or Customized Update Date:2010-12-10 8:58:53
